iKey AK-39-NV Wearable Keyboard

iKey's rugged AK-39-NV keyboard is designed to be worn on the arm, providing a simple, compact data-input solution that does not restrict the user's arm movements.
iKey AK-39-NV Wearable Keyboard

Overview

iKey's rugged AK-39-NV keyboard is designed to be worn on the arm, providing a simple, compact data-input solution that does not restrict the user's arm movements. It is designed to meet MIL-461 standards and is intended for use in very harsh electro magnetic interference (EMI) environments.

The AK-39-NV's small-footprint design features essential components for military and public safety applications, including an integrated Force Sensing Resistor (FSR) pointing device with left- and right-click functionality. The AK-39-NV also features six levels (including off) of adjustable green B LED backlighting that is night vision (NVIS) compatible. Designed with gloved users in mind, the AK-39's Snap-On faceplate eliminates accidental key strokes and can be easily removed to clean the pad.

Features

Rugged Wearable Design - Fits On Arm
Night Vision - NVIS Green B
Snap-On Faceplate
High Emi Standards

Technical Data

SKU
AK-39-NV
Manufacturer
iKey
Mounting Format
Wearable
IP Rating
IP68
Integrations
Force Sensing Resistor
No. Of Key
39
Key Switch
MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. ACTUATION FORCE: 230 g +/- 30 g) FEEDBACK: Tactile with Mechanical Snap
Keycap Profile
Industrial Silicone Rubber
Keycap Material
Industrial Silicone Rubber
Actuation Force
Tactile with Mechanical Snap
Connectivity
USB
Case Material
ABS Polycarbonate
Housing Colour
Black
Cable length
LENGTH: 5.4' straight (1.6 m) DESIGN: Single cable USB
Operating System
Windows, Mac OS X
Temperature Rating
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
Dimensions
6.65" x 3.06" x 0.81" (w-h-d) 168.9mm x 77.7mm x 20.6mm
Weight
0.50 lbs (0.23 kg)
Certifications
UL60950
