iKey PM-1000-NI Panel Mount Keyboard

iKey PM-1000-NI Panel Mount Keyboard

The nonincendive iKey PM-1000-NI is framed in stainless steel to ensure optimal durability and waterproof functionality.

IP rating
IP66
Mounting
Panel Mount
Connection
PS2, USB
Keys
114
  • Non-Incendive For Hazardous Environments
  • 114-Key Functionality
  • 24 Function Keys + 10-Key Numeric Pad
  • USB and PS2 Configurations Available
Request a quote View specifications

✓ Quotes within 24 hours  ·  ✓ Genuine products  ·  ✓ UK-based support

iKey PM-1000-NI Panel Mount Keyboard Request a quote

Overview

iKey offers a full line of Nonincendive keyboards and pointing devices.

The Nonincendive PM-1000-NI is framed in stainless steel to ensure optimal durability and waterproof functionality. It is designed to meet NEMA 4X specifications, which enables it to survive in the roughest of conditions.

The PM-1000-NI has a Factory Mutual approval of Class I, Division II. These units do not require barriers and are ideal for harsh working conditions. All units ship with bulkhead cables.

Features

Non-Incendive For Hazardous Environments
114-Key Functionality
24 Function Keys + 10-Key Numeric Pad
USB and PS2 Configurations Available

Technical Data

SKU
PM-1000-NI
Manufacturer
iKey
Mounting Format
Panel Mount
IP Rating
IP66
Integrations
No Pointer
No. Of Key
114
Key Switch
MATERIAL: Industrial silicone rubber LIFE: 10 million cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.03 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap
Keycap Profile
Industrial Silicone Rubber
Keycap Material
Industrial Silicone Rubber
Actuation Force
Tactile with Mechanical Snap
Connectivity
PS2,USB
Case Material
No Case
Cable length
LENGTH: 5 feet from keyboard to Bulkhead Connector DESIGN: 2 separate cables on PS/2 or single-cable USB
Operating System
Windows, Mac OS X
Temperature Rating
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
Dimensions
17.70" x 9.20" x 1.58" (w-h-d) 449.6mm x 233.7 mm x 40.1mm
Weight
5 lbs +/- 0.10 lbs (2.54 kg +/- 0.05kg)
Certifications
IP Rated, NEMA 4X UL60950, FCC Part 15 Class B Factory Mutual Class I, Division II
