iKey PM-2000 Panel Mount Keyboard

The iKey PM-2000 is constructed using a highly rugged stainless steel case and industrial silicone rubber pad, ensuring NEMA 4X protection in extremely rugged applications.

learn more

Overview

The PM-2000 is constructed using a highly rugged stainless steel case and industrial silicone rubber pad, ensuring NEMA 4X protection in extremely rugged applications. An integrated HulaPointTM pointing device offers additional usability.

The PM-2000 provides users with a full 114-key industrial keyboard and HulaPointTM industrial pointing device. It has two rows of function keys that allow for single keystroke access to software shortcuts.

Features

Rugged Stainless Steel Case
Integrated Pointing Device
24 Function Keys + 10-Key Numeric Pad
USB, PS2 and AT/Serial Configurations Available

Technical Data

SKU

PM-2000

Manufacturer

iKey

Mounting Format

Panel Mount

IP Rating

IP66

Integrations

HulaPoint

No. Of Key

114

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.03 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Keycap Profile

Industrial Silicone Rubber

Keycap Material

Industrial Silicone Rubber

Actuation Force

Tactile with Mechanical Snap

Connectivity

PS2,USB

Case Material

No Case

Housing Colour

Stainless Steel

Cable length

LENGTH: 10 feet (3 meters) DESIGN: "Y" PS/2 or AT/serial Cable (providing separate keyboard and mouse connections), or Single-Cable USB

Operating System

Windows, Mac OS X

Temperature Rating

STORAGE: -40C to +70C (-40F to +158F) OPERATING: -20C to +60C (-4F to +140F)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Dimensions

21.80" x 9.20" x 0.28" (w-h-d) 553.7mm x 233.7mm x 7.1mm SCREWS: 1.58" (40.1mm)

Weight

5.50 lbs +/- 0.10 lbs (2.49 kg +/- 0.05 kg)

Certifications

IP Rated, NEMA 4X, CE UL60950, FCC Part 15 Class B
