iKey PM-2000-TB Panel Mount Keyboard

The iKey PM-2000-TB is constructed using a highly-rugged stainless steel case and industrial silicone rubber pad, ensuring NEMA 4X protection in extremely rugged applications.
iKey PM-2000-TB Panel Mount Keyboard

Overview

The PM-2000-TB is constructed using a highly-rugged stainless steel case and industrial silicone rubber pad, ensuring NEMA 4X protection in extremely rugged applications.

The PM-2000-TB provides users with a full 114-key industrial keyboard and trackball industrial pointing device. It has two rows of function keys that allow for single keystroke access to software shortcuts. The laser trackball pointing device is integrated into the keyboard for additional usability.

Features

Integrated Trackball
114-Key Functionality
24 Function Keys + 10-Key Numeric Pad
PS2 and Separate-Cable USBconfigurations Available

Technical Data

SKU
PM-2000-TB
Manufacturer
iKey
Mounting Format
Panel Mount
IP Rating
IP66
Integrations
Trackball
No. Of Key
114
Key Switch
MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.03 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap
Keycap Profile
Industrial Silicone Rubber
Keycap Material
Industrial Silicone Rubber
Actuation Force
Tactile with Mechanical Snap
Connectivity
PS2,USB
Case Material
No Case
Cable length
LENGTH: 10 feet (3 meters) DESIGN: "Y" PS/2 or two USB cables
Operating System
Windows, Mac OS X
Temperature Rating
STORAGE: -40C to +85C (-40F to +185F) OPERATING: 0C to +55C (+32F to +131F)
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
Dimensions
21.80" x 9.20" x 0.44" (w-h-d) 553.7mm x 233.7mm x 11.2mm SCREWS: 1.58" (40.1mm)
Weight
5.75 lbs +/- 0.10 lbs (2.61 kg +/- 0.05 kg)
Certifications
IP Rated, NEMA 4X, CE UL60950, FCC Part 15 Class B

Where to Buy

Are you on the hunt for the iKey PM-2000-TB Panel Mount Keyboard? Look no further!

Let us do the heavy lifting for you!

With our extensive experience and close relationships with top manufacturers and suppliers, we are here to help you source exactly what you need.

Best Price | 100% Genuine Product | UK Warranty | Customer & Technical Support!

Don't waste your time scouring the internet for hours on end, just fill out the simple form below and one of our keyboard specialists will provide you with a competitive quotation in no time.
