iKey PM-65-TB-SS Panel Mount Keyboard

iKey PM-65-TB-SS Panel Mount Keyboard

A vandal-resistant 65-key stainless steel panel mount keyboard with a sealed laser trackball, for unattended kiosks, retail and industrial use.

IP rating
IP65
Mounting
Panel Mount
Connection
PS2, USB
Keys
65
  • Rugged Stainless Steel Case
  • Vandal Proof Design
  • Integrated, Programmable Function Keys
  • Various Keyboard and Language Layout Options
Request a quote View specifications

✓ Quotes within 24 hours  ·  ✓ Genuine products  ·  ✓ UK-based support

iKey PM-65-TB-SS Panel Mount Keyboard Request a quote

Overview

The iKey PM-65-TB-SS is a stainless steel panel mount keyboard with a built-in laser trackball, designed for public display kiosks and other unattended installations. Stainless steel keys, an easily mounted design and a durable build help prevent theft and damage from vandals.

The keyboard is cleanable, waterproof and can be customised to suit the application, with programmable function keys and a choice of keyboard and language layouts. The laser trackball is easy to use and completely sealed for protection.

Key features

  • Waterproof, vandal-resistant design rated IP65
  • 65 stainless steel keys, including integrated programmable function keys
  • Sealed 38 mm laser trackball
  • Stainless steel case with various keyboard and language layout options
  • 412.8 x 130.0 x 28.4 mm front panel, with a 400.1 x 117.3 mm panel cutout
  • Operating temperature of -40°C to +60°C
  • USB or PS/2 connection with a straight cable of approximately 2.1 m

Where it is used

The PM-65-TB-SS is aimed at kiosks and public access terminals, retail and point of sale, and industrial installations.

Get a quote

If you are specifying keyboards for a kiosk project, send us your layout and quantity via the quote form on this page. We will reply within 24 hours.

Features

Rugged Stainless Steel Case
Vandal Proof Design
Integrated, Programmable Function Keys
Various Keyboard and Language Layout Options

Technical Data

SKU
PM-65-TB-SS
Manufacturer
iKey
Mounting Format
Panel Mount
IP Rating
IP65
Integrations
Trackball
No. Of Key
65
Key Switch
MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 6.35 oz. +/- 0.70 oz. (180g +/- 20g) FEEDBACK: Tactile with a Mechanical Snap
Keycap Profile
Stainless Steel
Keycap Material
Stainless Steel
Actuation Force
Tactile with Mechanical Snap
Connectivity
PS2,USB
Case Material
Stainless Steel
Housing Colour
Stainless Steel
Cable length
LENGTH: 7' straight
Operating System
Windows, Mac OS X
Temperature Rating
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +60C (-40F to +140F)
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
Dimensions
Front Panel: 16.25" x 5.12" x 1.12" (412.8 x 130.0 x 28.4 mm) Panel Cutout: 15.75" x 4.62" (400.1 x 117.3 mm) Trackball: 38mm Diameter
Weight
4.00 lbs +/- 0.10 lbs (1.84 kg +/- 0.05 kg)
Certifications
Meets or exceeds: IEC 60512-6 IEC 60512-4 IP65 FCC part 15, class B
