iKey RDC-1000 Rackmount Keyboard

RDC-1000 Rack drawer Industrial Keyboard From iKey Keyboards
iKey RDC-1000 Rackmount Keyboard

Overview

Ruggedized Rack drawer keyboards from iKey corner the market on rackmount peripherals.

The RDC-1000 features an industrial silicone rubber keypad with 114 keys and a full-size number pad. Standard size units have 14-inch rails (15-inch-deep drawer) and come with chrome handle or pull slot options. Larger size units have 16-inch rails (17-inch drawer) and come with T-handle or locking T-handle options. The drawers have a CRS steel construction, which is coated with black epoxy paint and chrome-plated, ball-bearing slides.

(Model shown in photo is the pull slot option, part number RDC-1000-NH)

Features

114 Keys and A Full-Size Number Pad
Slide Load Rating: 130 Lbs/Pair
USB, PS2 and AT/Serial Configurations Available
ABS Polycarbonate Frame With Mounting Studs

Technical Data

SKU
RDC-1000
Manufacturer
iKey
Mounting Format
Rackmount
IP Rating
IP66
Integrations
No Pointer
No. Of Key
114
Key Switch
MATERIAL: Industrial silicone rubber LIFE: Greater Than 10 million cycles TRAVEL: 0.055 in. ACTUATION FORCE: 200g (+/- 20g) FEEDBACK: Tactile with mechanical snap
Keycap Profile
Industrial Silicone Rubber
Keycap Material
Industrial Silicone Rubber
Actuation Force
Tactile with Mechanical Snap
Connectivity
PS2,USB
Case Material
Metal Rackmount
Housing Colour
Black
Cable length
LENGTH: 10 feet (3 meters) DESIGN: "Y" PS/2, AT or Single-Cable USB
Operating System
Windows, Mac OS X
Temperature Rating
STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)
Vibration
POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours
Dimensions
Pull Slot/Chrome Handle: 19" x 15" x 1U (1.75") 482.6mm x 381mm x 44.5mm T-Handle: 19" x 17" x 1U (1.75") 482.6mm x 431.8mm x 44.5mm
Weight
12.5 lbs (5.67 kg)
Certifications
NEMA 12, CE UL60950, FCC Part 15 Class B
