iKey SLP-86-911-461-FSR Panel Mount Keyboard

Designed to meet MIL-STD-461 standards, the SLP-86-911-461 is ideal for harsh environments where electromagnetic interference is a top concern.

learn more

iKey SLP-86-911-461-FSR Panel Mount Keyboard

Overview

Designed to meet MIL-STD-461 standards, the SLP-86-911-461 is ideal for harsh environments where electromagnetic interference is a top concern.

In addition, the SLP-86-911-461 features an emergency key that, when pressed, sends a signal of Shift+F1 and lights up for 30 seconds. The SLP-86-911-461 integrates the Force Sensing Resistor, an upgraded pointing device that offers improved sensitivity and increased durability. It boasts a completely sealed and ruggedized construction that, when properly sealed, allows it to meet NEMA 4X specifications, ensuring that this keyboard is sealed against the elements or unwanted spills.

Features

Designed To Meet MIL-STD-461F
Integrated LED Backlighting
One-Touch Emergency Key
86-Key Functionality

Technical Data

SKU

SLP-86-911-461-FSR

Manufacturer

iKey

Mounting Format

Panel Mount

IP Rating

IP66

Integrations

Force Sensing Resistor

No. Of Key

86

Key Switch

MATERIAL: Industrial Silicone Rubber LIFE: Greater than 10 Million Cycles TRAVEL: 0.055 in. (1.4mm) ACTUATION FORCE: 7.05 oz. +/- 1.06 oz. (200g +/- 30g) FEEDBACK: Tactile with Mechanical Snap

Keycap Profile

Industrial Silicone Rubber

Keycap Material

Industrial Silicone Rubber

Actuation Force

Tactile with Mechanical Snap

Connectivity

PS2,USB

Case Material

No Case

Housing Colour

Black

Cable length

Single-Cable USB

Operating System

Windows, Mac OS X

Temperature Rating

STORAGE: -40C to +90C (-40F to +194F) OPERATING: -40C to +70C (-40F to +158F)

Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Dimensions

11.80" x 6.79" x 1.35" (w-h-d) 299.7mm x 172.5mm x 34.3mm CUTOUT: 10.40" x 5.40" (w-h) 264.2mm x 137.2

Weight

1.75 lbs (0.79 kg)

Certifications

NEMA 4X, CE UL60950, FCC Part 15 Class B
