iKey TMLT-870-OEM OEM Keyboard

iKey's TMLT-870-OEM keyboard packs full military specifications into an extremely thin, 0.43" depth, making it ideal for rugged applications.
iKey TMLT-870-OEM OEM Keyboard

Overview

iKey's TMLT-870-OEM keyboard packs full military specifications into an extremely thin, 0.43" depth, making it ideal for rugged applications.

Designed to meet MIL-461E standards, the TMLT-870-OEM has excellent performance for conducted and radiated emissions, including RS103 and 200 volts/meter.

The TMLT-870-OEM's top-mounted assembly eliminates the need to dismantle laptop components to reach the keyboard. In addition, it features an integrated FSR pointing device and adjustable green LED backlighting, with optional NVIS Green B.

Features

Designed To Meet Mill-Std-461E
Integrated Fsr Pointing Device
Optional NVIS Compliant Green B Backlighting
Switch Matrix Configuration

Technical Data

SKU
TMLT-870-OEM
Manufacturer
iKey
Mounting Format
OEM
IP Rating
IP66
Integrations
HulaPoint
No. Of Key
87
Key Switch

POWER SPECTRAL DENSITY: 0.04g2/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Keycap Profile

Industrial Silicone Rubber

Keycap Material

Industrial Silicone Rubber

Actuation Force

Tactile with Mechanical Snap

Connectivity
PS2,USB
Case Material
No Case
Operating System
Windows, Mac OS X
Temperature Rating
STORAGE: -51C to +71C OPERATING: -32C to +60C
Vibration

POWER SPECTRAL DENSITY: 0.04g/Hz FREQUENCY RANGE: 20Hz - 2 kHz DURATION OF TEST PER AXIS: 3 hours

Dimensions
12.59" x 6.59" x 0.43" (w-h-d) 319.79mm x 167.39mm x 10.92mm
Weight
0.6 lbs (0.27 kg)
Certifications
IP Rated, NEMA 4X UL60950, FCC Part 15 Class B
